The Orion Tr charger can be used in 12V or 24V systems and is suitable for both lead acid.

Features

• High efficiency.
• IP43 protection.
• Screw terminals.

Technical Specifications

• Input voltage range: 18-35V.
• Output voltage: 12.5V.
• Efficiency: 97%.
• Continuous output current: 15A.
• Max. Output current: 20A.
• Galvanic isolation: No.
• Off load current: <35mA.
• Operating temperature range (derate 3% per °C above 40°C): -20 to 55°C.
• DC connection: Screw terminals.
• Maximum cable cross-section: 6mm² AWG12.
• Weight: 0.25kg.
• Dimensions (hxwxd): 73mm x 94mm x 45mm.
