All models with adjustable output can be paralleled to increase output current.
Up to five units can be connected in parallel.

Features:

• Remote on-off connector.
• All models with adjustable output can also be used as a battery charger.
• Easy to install.
• All models with adjustable output can be paralleled to increase output current.
• Low power model.

Technical Specifications:

• Input voltage: 18-35.
• Output voltage: Adjustable 10–15V F set 13,2V.
• Efficiency: 92%.
• Continuous output current: 70.
• Max. Output current: 85.
• Galvanic isolation no.
• Off load current: <20mA.
• Remote on-off: yes.
• Operating temperature range: -20 to 55°C.
• DC connection: M6 bolts.
• Weight: 0.9.
• Dimensions hxwxd: 65x88x195.
