The AIMS Power 100 amp charge controller uses advanced digital control technology, includes a LCD display and fully automatic operation. The controller uses MPPT technology and provides three charging stages and improves battery storage and charging efficiency. This charge controller can also be connected in parallel for multiple units if needed.

100 Amp MPPT Solar Charge Controller For 300V Inverters Features

• Advanced digital control technology
• LCD display – 3″
• MPPT technology
• Pre drilled holes for easy mounting
• Temperature compensation functions for battery type
• RS-485 communication port – Modbus separate
• 3 stage charging
• Works with 300V inverters only

100 Amp MPPT Solar Charge Controller For 300V Inverters Specifications

• Voltage: 300-384V
• Max VOC of PV arrays: 800V
• Max charging current: 100A
• Inputs: 1 group
• Equalize charging point: 460.8V
• Float charging point: 441.6V
• Over voltage: 512V
• Over voltage recovery: 480V
• Equalize charging recovery: 422.4V
• Stand-by consumption: <.5 Watt
• Terminal type: TC series barrier terminal
• Humidity: 0-98%, non-condensing
• Environment temperature: -13 F to 131 F
• Elevation: < 4000M, may have reduced power higher than 4000M
• Protection level: IP32
• Noise: <30dBA
• Dimensions: 19.5″ x 15″ x 9″
• Weight: 60

*Some specifications can be changed depending on battery type.
