Advantage Environmental Lighting XEM11 Chicago Approved LED Edgelit Exit Signs - Recessed Mount

ILLUMINATION

• Ultra-bright, energy efficient, long-lasting white LEDs provide uniform illumination.
• UV stabilized, silk screened acrylic panels provide consistent, uniform illumination.
• Single or double face configurations.

ELECTRICAL

• Dual 120V/277V.
• Charge rate/power “ON” LED indicator light and push to test switch for mandated code compliance testing.
• 4.8V Long-life, maintenance-free, rechargeable NiCd battery (EM models only).
• Internal solid-state transfer switch automatically connects the internal battery to LED board for minimum 120-minute emergency illumination.
• Fully automatic solid-state, two-rate charger initiates battery charging to recharge a discharged battery in 24 hours.

MOUNTING

• Compatible with drywall or drop-thru ceiling mount installations.
• Wall mount capability optional.
• HOUSING
• Premium-grade, extruded aluminum housing.
• Trim assembly is easily detachable, providing accessibility for service or maintenance.

OPTION

• WM: Wall mount.

WARRANTY/LISTING

• Five year warranty on all electronics and housing. Battery pro-rated for fi ve years.
• UL listed for damp locations (0°-50°C/32°F-122°F standard).
• Meets UL924, NFPA101 Life Safety Code, NEC, OSHA, Local and State Codes.
• Meets city of Chicago requirements.
