Technical Specifications

• Inveter Connection: 5 Wire-L1-L2-L3-N-E
• Recommended inverter Cable size (inverter input): 35mm2/core.
• Circuit Breaker Current Rating - Inverter Input Non - Adjustable: 125A.
• Circuit Breaker Current Rating -Main Output Non - Adjustable: 125A.
• Number of inverter Inputs : 4.
• Number of Outputs: 4.
• Enclosure Material: Mild Steel
• Enclosure Material: Thickness 1,6mm.
• Enclosure Colour: B26 Orange.
• Mounting Wall: 1 x set of 4 wall brackets.
• Door opening: Hinged on side Lever Lock.
• Internal Cover Plate: White Removable Yes.
• Internal Componets pre-wired: Yes.
• Panel AC Fualt level: 10kA.
• System Voltage: 1000V.
• IP Rating: IP65.
• Earth Stud: YES.
• Dimensions Height/Width/Depth(mm): 500 x 310 x 160.
